测量范围 Operating range:1-100pa、6-41000kpa、1-60MPa

工作电压 Operating voltage:12-36Vdc

响应时间Response time:{<}1ms (10. 90%FS)

工作温度 Operating temperature:-35 ℃-85℃

精度 Accuracy: 表压Gauge pressure:士0.075%FS GB 型0.1%FS AB 型

材质Material:Stainless steel 316LPTFE、PP

• 精密滤油机主要由粗滤器、齿轮油泵、一级精过滤器、二级精过滤器、安全阀、压力表、进出口阀门及移动小车组成。

• 粗过滤器是一个网式过滤器，分两级粗过滤，滤网为不锈钢网，一级为40目，二级为60目。

• 精过滤元件是由棉脱脂后的棉纤维滤层材料缠绕在多孔不锈钢骨架上形成蜂房式滤芯，本滤芯孔径外大内小，具有优良的深层过滤效果。

• 齿轮油泵设有安全阀（出厂时安全阀压力调节在工作压力的150%左右）。




• Fine filter mainly consists of coarse filter, Stage I Fine Filter,Stage 2 Fine Filter, a safety valve, a pressure gauge, inlet/ outlet valve and a movable cart.

• Coarse filter is of screened one, which is composed of two stages of filtering. And screen is made of stainless steel. First stage is of 40 mesh and second stage ts of 60mesh.

• Fine filter element is honeycomb filter core (Defatted cotton layers wound around multi-pore stainless steel frame). The filter core has bigger outer diameter and smaller inner diameter, having good filtering result.

• Gear oil plump is provided with a safety valve.The valive was set to 150% of operating pressure when it left factory.The follows are your options.

• KJ/KJA型快速/自封快速活接头

• 透明钢丝耐油胶管

• 泵轴封

• SS-C蜂房高精滤芯

• Mode| KI/KJA quick/ self sealing adapter.

• Transparent wire oil-proof rubber tube.

• SS-C horeycomb fine core.
